HSQY food tray lidding film rolls and production line
B2B FOOD PACKAGING SOLUTIONS

Food Tray Lidding Film Manufacturer for Reliable Heat Sealing

Match the sealant layer to your tray flange, filling process and opening experience. HSQY supplies easy-peel, lock-seal, anti-fog, high-barrier and retort-ready structures for PET, PET/PE, CPET and PP trays.

For an accurate recommendation, send a physical tray or the complete tray flange structure. Review the matching guide ↓

20+ Years Plastics industry experience
12+ Factories Invested and partnered network
40+ Lines Integrated production capacity
OEM Support Samples, sizing and printing
START WITH COMPATIBILITY

The right film starts with the tray flange

A film can look suitable and still deliver weak seals, tearing or contamination failures. The first question is not simply “PET or PP?”—it is which material is present on the tray’s sealing surface.

Best practice: confirm tray structure, target seal style, packed food, process temperature and machine settings before a production run.
QUICK MATCHING GUIDE

Choose a practical starting structure

These are starting points for sampling, not universal specifications. Final suitability must be confirmed on your tray and sealing line.

Tray / flange Recommended starting point Available seal options Trial focus
APET / PETMono PET or coated flange Coated BOPET or PET-compatible sealant Easy peel or lock seal Coating type, clarity, peel consistency
PET/PEPE sealing surface PET/PE with a PE-compatible sealant Easy peel, lock seal, anti-fog Leak resistance and chill performance
CPETTemperature-resistant tray Validated CPET-compatible heat-resistant film Easy peel or lock seal Oven/microwave cycle and post-process seal
PPPP sealing surface PP-compatible coated film or PET/PA/RCPP structure Peelable, lock seal, retort option Process temperature and opening force
Not sure which sealing layer is on your tray? Send the tray material, flange structure, packed food and machine details for a project-specific starting recommendation.
Ask a Film Specialist
PRODUCT RANGE

Lidding films organized by buying requirement

Select the tray material used on your sealing flange. Each tab shows up to eight relevant products and links to the full category when more options are available.

Choose lidding films by tray material
8 PRODUCTS SHOWN

Lidding Films for APET Trays

Start with a PET-compatible sealant, then confirm coating, peel style, barrier and actual tray-flange performance.

View more APET films
Additional APET film formats are available. View More APET Products
4 PRODUCT FAMILIES

Lidding Films for CPET Trays

Film, tray, food and heating cycle must be validated as one packaging system for microwave or oven applications.

CPET selection guide
8 PRODUCTS SHOWN

Lidding Films for PP Trays

Choose between easy-peel, lock-seal, barrier and retort structures according to the actual PP flange and process.

View more PP films
Additional PP, barrier and retort structures are available. View More PP Products
5 PRODUCT FAMILIES

Lidding Films for PET/PE Trays

Match the lidding film to the PE sealing surface, then select peel, anti-fog or barrier performance around the packed food.

PET/PE selection guide
NEED A COMPATIBILITY CHECK?

Send your tray and sealing requirements before choosing a film.

Include the tray flange layer, food, process, seal style, machine and roll dimensions.

Discuss Your Lidding Film Project
FUNCTIONAL OPTIONS

Specify performance around the packed product

Combine only the functions your application needs. This keeps the structure practical and helps make trials more conclusive.

01

Easy Peel

Controlled opening for consumer-friendly packs, with peel force tuned through trials.

02

Lock Seal

Strong, secure sealing for leakage-sensitive or distribution-intensive applications.

03

Anti-Fog

Helps maintain product visibility in chilled produce, meal and protein packs.

04

High Barrier

Structures available for oxygen- and moisture-sensitive foods or MAP projects.

05

Heat & Retort

Temperature-resistant options for validated CPET or PP processes and end-use cycles.

06

Custom Printing

Flexographic or gravure printing options for branding, instructions and retail presence.

Need help prioritizing peel, barrier, anti-fog or heat-process performance?

Talk to Our Sales Team
RFQ CHECKLIST

Six inputs for a faster film recommendation

Complete specifications reduce trial rounds and help the engineering team recommend a realistic starting structure.

Send Your Packaging Brief
  1. 1
    Tray material and flange layer

    APET, PET/PE, CPET or PP; include any coating or sealant details.

  2. 2
    Food and packing process

    Fresh, chilled, frozen, hot-fill, MAP, microwave, oven or retort.

  3. 3
    Opening requirement

    Easy peel, weld/lock seal, target peel feel or tamper-evidence need.

  4. 4
    Barrier and visibility

    Target shelf life, OTR/WVTR expectations, anti-fog and clarity.

  5. 5
    Machine and roll dimensions

    Sealer model, roll width, maximum OD, core ID, speed and seal window.

  6. 6
    Commercial details

    Printing artwork/colors, forecast volume, destination and trial quantity.

APPLICATIONS

Built for modern tray-sealing programs

Film structure is selected around the food, process and distribution chain—not the food category alone.

01

Ready Meals

Chilled, frozen, airline and institutional meal trays, including heat-process projects.

02

Fresh Produce

Cut fruit, vegetables and salads where clarity and anti-fog help presentation.

03

Meat & Poultry

Leak-sensitive and MAP packs requiring dependable seals and tailored barrier.

04

Seafood & Deli

Chilled protein and prepared-food packs with peelable or lock-seal formats.

MANUFACTURING SUPPORT

From rollstock production to converting

HSQY entered food packaging in 2019 and supports projects through a network of invested and partner factories, with lidding films, trays and compatible packing equipment in the wider portfolio.

HSQY lidding film production and converting equipment
Film converting Rollstock handling and production support
HSQY factory hall with packaged lidding film rolls
Factory network Scalable manufacturing resources
Industrial lidding film extrusion and coating production line
Process capability Coating, lamination and film production
PUBLISHED REFERENCE DATA

Use test values as a baseline, then qualify your grade

The values shown are reference figures published on HSQY’s current category page for a representative film. They are not guaranteed values for every structure, thickness or test condition.

Request a grade-specific technical data sheet, compliance documents and samples before commercial approval.

35 ± 2 μm Reference thickness
± 2 mm Reference width tolerance
≥ 3.5 N/15 mm Heat-seal strength*
≤ 3% Reference shrinkage
≤ 20 WVTR g/(m²·24 h)
≤ 120 OTR cm³/(m²·24 h·0.1 MPa)

*Published heat-seal test condition: 195°C / 5 kg / 3 s. Actual results depend on tray, seal surface, dwell time, pressure and equipment.

PROJECT WORKFLOW

A trial-led path to production

Qualification is built around your tray and sealing conditions so decisions are based on real pack performance.

01

Share Requirements

Send tray structure, packed food, machine and process details.

02

Shortlist Structure

HSQY recommends a film family and relevant functional options.

03

Sample & Trial

Test sealing window, peel behavior, leakage and post-process performance.

04

Approve & Produce

Confirm specifications, artwork, roll format and commercial order.

B2B LIDDING FILM FAQ

Questions procurement and packaging teams ask

These answers help food manufacturers, distributors and packaging buyers prepare a more complete sourcing enquiry. Grade-specific suitability still requires tray and line validation.

Ask a Technical Question

How do I match lidding film to an APET, CPET, PP or PET/PE tray?

Match the film’s sealant layer to the material exposed on the tray flange. Confirm the complete tray structure, any coating, required seal style, food, process temperature and machine settings, then validate the shortlist on the actual line.

What specifications should a B2B buyer provide for a lidding film quotation?

Provide the tray material and flange layer, food and packing process, easy-peel or lock-seal requirement, barrier and anti-fog targets, roll width, core ID, maximum roll OD, sealing machine, printing needs, forecast volume and destination. A physical tray sample improves film matching.

What is the difference between easy-peel and lock-seal lidding film?

Easy-peel film prioritizes controlled consumer opening; lock-seal film prioritizes stronger package integrity. Select between them according to product weight, liquids, distribution stress, tamper-evidence needs and the intended opening experience.

When should food manufacturers specify anti-fog lidding film?

Specify anti-fog performance when condensation could reduce product visibility, particularly for chilled produce, ready meals and protein packs. Test the film under the actual filling, cooling, storage and retail temperature cycle.

When is high-barrier lidding film needed for MAP food packaging?

High-barrier film is considered when the food, target shelf life and gas atmosphere require lower oxygen or moisture transmission. The lidding film and tray must provide compatible barrier performance; confirm the target values for the selected structure.

Can lidding film be used for CPET oven heating or PP retort processing?

Heat-resistant and retort film structures are available, but the polymer name alone does not confirm suitability. Validate the exact film, tray, food, maximum temperature, cycle time, pressure and seal conditions as a complete pack.

Can HSQY supply custom-printed lidding film rolls?

Custom printing can be discussed for suitable film structures. Share the artwork, number of colors, repeat length, registration requirements, roll direction, machine details and forecast volume for a feasibility review.

How are MOQ, sampling and lead time confirmed for a wholesale order?

MOQ, sample format and lead time depend on the film structure, width, thickness, printing and order volume. Send the complete specification and delivery destination for a project-specific quotation and schedule.

Lidding film rolls and sealed food tray ready for a packaging trial
READY TO QUALIFY YOUR FILM?

Send your tray details. Start with a sample.

Tell us the flange structure, food, process and machine conditions. HSQY will help shortlist a film for trial.

START AN INFORMED RFQ
