HSQY Transparent Color PC Rigid Film 0.18mm-0.8mm
HSQY transparent color PC rigid film is made from 100% new polycarbonate material. It is suitable for PC card material, polycarbonate overlay film, plastic card making, laser engraving cards, laser printing cards, security cards and other precision plastic film applications.
Polycarbonate rigid film offers high transparency, excellent impact resistance, strong dimensional stability, good heat resistance and reliable printing performance. It can be supplied in transparent, porcelain white, milk white and customized colors with smooth, frosted, glossy or matte surfaces.
PC Rigid Film Product Specifications
HSQY supplies polycarbonate overlay film and PC card material in multiple thicknesses, colors and surface finishes. Custom thickness, color, surface and printing compatibility can be arranged according to customer requirements.
| Product Name |
PC card material, polycarbonate overlay film |
| Material |
100% new polycarbonate material |
| Color |
Porcelain white, milk white, transparent and customized colors |
| Surface |
Smooth, frosted, glossy, matte |
| Thickness Range |
0.05mm, 0.06mm, 0.075mm, 0.10mm, 0.125mm, 0.175mm, 0.25mm or customized |
| Process |
Calendering |
| Application |
Plastic card making, laser engraving card, laser printing card |
| Printing Options |
CMYK offset printing, silk-screen printing, UC security printing, laser printing |
Key Advantages of Polycarbonate Rigid Film
High light transmission, up to 88% of the same thickness of general glass.
Excellent impact resistance, about 80 times that of glass.
Weather and UV resistance for long-term performance and reduced yellowing.
Temperature resistance range from -40°C to +120°C.
Lightweight structure, only about 1/12 of the weight of glass with the same thickness.
Can be cold bent, thermoformed and processed for different applications.
Good flame resistance with B1 fire performance rating.
Excellent physical, mechanical, electrical and heat performance as an engineering plastic.
PC Sheet and PC Film Material Applications
Polycarbonate material is widely used in electronic appliances, mechanical equipment, medical equipment, construction and card manufacturing. PC rigid films are especially suitable for card overlay, printing, laser engraving and security card applications.
Electronic appliances: insulating plug-ins, coil frames, tube sockets and battery shells.
Mechanical equipment: gears, racks, bolts, levers, crankshafts, covers and housings.
Medical equipment: cups, tubes, bottles, dental equipment and pharmaceutical equipment parts.
Construction: hollow sheets, greenhouse glazing, protection panels and building materials.
Card manufacturing: plastic cards, laser engraving cards, laser printing cards and security cards.
![PC rigid film and PC sheet material application]()
Packing of PC Rigid Film
HSQY provides protective packing for PC rigid films and polycarbonate sheets to reduce surface scratches, deformation and transportation damage. Customized packing can be arranged according to sheet size, roll format and export requirements.
![PC rigid film and polycarbonate sheet packing]()
Company Introduction
Changzhou Huisu Qinye Plastic Group Co., Ltd. specializes in the production and sales of PC board, PC endurance board, PC diffusion board and PC sheet processing. Processing services include engraving, bending, precision cutting, punching, polishing, bonding, thermoforming, blister forming within 2.5*6 meters, ABS thick plate blister, UV flatbed printing and screen printing.
With more than 16 years of export experience, HSQY provides high-quality PC sheets, PC rigid films and customized polycarbonate material solutions to customers worldwide.
You have reason to choose polycarbonate board and PC rigid film from Huisu Qinye Plastic Group.
FAQ
What is PC rigid film used for?
PC rigid film is used for plastic card making, polycarbonate overlay film, laser engraving cards, laser printing cards, security cards, electronic insulation, printing and other precision plastic film applications.
What is the fire rating of polycarbonate sheet?
Polycarbonate material can reach B1 fire rating, which provides good flame resistance for applications that require safer engineering plastic materials.
Is polycarbonate unbreakable?
Polycarbonate is highly impact-resistant and is often described as virtually unbreakable in normal use. However, no material can be guaranteed 100% unbreakable under extreme conditions such as explosions or ballistic impact.
Can I cut polycarbonate sheets at home?
Yes. Polycarbonate sheets can be cut with tools such as a jigsaw, band saw or fret saw. HSQY also provides cut-to-size service to help customers reduce processing work.
How should I clean polycarbonate sheet?
Clean polycarbonate sheet with warm soapy water and a soft cloth. Do not use abrasive materials, harsh solvents or rough cleaning tools because they may damage the surface.
What is the difference between polycarbonate and acrylic?
Polycarbonate has much higher impact resistance and better fire performance than acrylic. Acrylic is stronger than glass but can break or shatter under force, while polycarbonate is more suitable for impact-resistant applications.
Do PC sheets discolor over time?
With a transparent UV protective layer, PC sheets can resist discoloration and yellowing for long-term outdoor use. Service life depends on material grade, UV protection, installation environment and maintenance.
What information is needed for a quotation?
Please provide the required thickness, color, surface finish, size or roll format, application, printing requirements, quantity and destination port. HSQY can recommend suitable PC rigid film or PC sheet solutions.
