6mm 8mm 10mm Polycarbonate Sheet for Sound Insulation
HSQY 6mm, 8mm and 10mm solid polycarbonate sheets are designed for sound-insulation partitions, transparent noise barriers, construction glazing and other projects requiring a combination of visibility, impact resistance and lightweight handling.
The current product specification uses 100% new polycarbonate and offers transparent, opaque white and milk white options together with smooth, frosted, glossy and matte surfaces. Customized thicknesses and dimensions can also be discussed according to project requirements.
For sound-insulation projects, sheet thickness is only one part of the acoustic system. Final performance also depends on panel dimensions, supporting frame, joints, seals, installation height, surrounding structure and the required acoustic test method.
These sheets are intended for B2B buyers including partition-system manufacturers, construction contractors, noise-barrier fabricators, distributors and engineering companies requiring customized PC sheet specifications.
Request Polycarbonate Sheet Pricing Request Project Samples
Polycarbonate Sheet Product Display
PC Sheet for Partition Walls
![6mm Polycarbonate Sheet for Construction]()
PC Sheet for Construction
![Transparent PC Sheet for Sound Insulation]()
PC Sheet for Freeway Barriers
Polycarbonate Sheet Specifications
| Property | Details |
| Product Name | Sound Insulation Polycarbonate Sheet |
| Material | 100% New Polycarbonate |
| Featured Thicknesses | 6mm, 8mm, 10mm |
| Customized Thickness | Available subject to production and project requirements |
| Current Product Attribute Range | 0.8–15mm according to the current product-page attribute field |
| Standard Size Reference | 1220 × 2400mm, 1200 × 2150mm, Custom Size |
| Color | Opaque White, Milk White, Transparent |
| Additional Color Options | Clear, Clear with Color, Opaque Color according to current product attributes |
| Surface | Smooth, Frosted, Glossy, Matte |
| Process | Calendering according to current product specification |
| Printing Options | CMYK Offset Printing, Silk-Screen Printing, UV Security Printing, Laser Printing |
| Primary Applications | Partition Walls, Transparent Noise Barriers, Construction and Engineering Applications |
| Listed Documents | ISO 9001:2008, SGS, ROHS |
Final thickness, dimensions, UV configuration, color, surface and project performance should be confirmed for the exact supplied sheet before bulk production or engineering approval.
Send Your PC Sheet Specifications
6mm vs 8mm vs 10mm Polycarbonate Sheet
Thickness selection for a sound-insulation or partition project should consider more than acoustic performance alone. Panel dimensions, supporting-frame spacing, wind load, impact requirements, deflection limits, installation method and project standards can all affect the final choice.
| Thickness | Typical Project Consideration |
| 6mm | Lower panel mass and easier handling for suitable partitions or transparent barrier projects |
| 8mm | Intermediate thickness where additional rigidity or acoustic mass is required |
| 10mm | Greater panel thickness for projects requiring higher rigidity, mass or structural margin |
HSQY does not recommend selecting a noise-barrier panel solely by thickness. Provide the required acoustic specification, panel size, frame spacing, installation environment and applicable engineering standard when requesting a project quotation.
How Polycarbonate Sheets Work in Sound Barrier Systems
Solid polycarbonate sheets can form the transparent panel component of an acoustic barrier or partition system. The sheet interrupts the direct transmission path between the noise source and the receiver while maintaining light transmission and visibility.
Actual installed sound reduction is determined by the entire system rather than the sheet alone. Panel height, width, thickness, supporting posts, joints, seals, openings, installation position and surrounding structures can all influence final acoustic performance.
For projects with a defined sound-reduction requirement, provide the required dB value and applicable test standard so the sheet and complete barrier design can be evaluated against the project specification.
Key Features of Sound Insulation Polycarbonate Sheet
High Light Transmission: The current product description lists light transmission up to approximately 88% for suitable clear PC sheet configurations. Actual transmission depends on thickness, color, surface and material grade.
Impact Resistance: Existing HSQY product information states impact resistance up to 80 times that of glass under the referenced conditions. Buyers requiring a specific impact rating should request the applicable test data.
UV and Weather Options: The existing description references outdoor weather resistance and operation from approximately -40°C to +120°C. Confirm the exact UV-protected grade, exposure conditions and technical data for outdoor projects.
Lightweight Handling: Polycarbonate is lighter than equivalent glass panels, helping simplify transportation, lifting and installation for suitable projects.
Fire Performance: The current HSQY description lists Class B1 fire resistance. Because fire ratings depend on the applicable standard, grade and thickness, request the corresponding report when a defined classification is required.
Sound Barrier Potential: Solid PC sheets can be incorporated into transparent partition and acoustic-barrier systems. Final acoustic performance depends on the full installation configuration.
Engineering Plastic: Polycarbonate combines optical clarity, toughness and fabrication capability for selected construction, glazing and industrial applications.
Polycarbonate Sheet for Partition Walls
Transparent polycarbonate sheets can be used in interior partition systems where daylight, visual openness, impact resistance and physical separation are required.
For office, industrial or commercial partitions, buyers should specify the required panel thickness, dimensions, surface, transparency, frame system and acoustic requirement before selecting the final sheet configuration.
| Partition Requirement | Information to Confirm |
| Panel Thickness | 6mm, 8mm, 10mm or required customized thickness |
| Panel Size | Required width × length and frame opening |
| Transparency | Transparent, milk white or opaque white |
| Surface | Smooth, frosted, glossy or matte |
| Acoustic Requirement | Required sound-reduction target and test method |
| Supporting System | Frame material, spacing, seals and fixing method |
Polycarbonate Sheet for Highway and Freeway Noise Barriers
Solid transparent polycarbonate can be used as the clear panel element in highway, freeway and transport noise-barrier systems where visibility and impact resistance are required.
Outdoor barrier projects should specify UV protection, wind load, panel dimensions, frame spacing, impact requirements, acoustic performance and local engineering standards before material approval.
Where abrasion, vandalism or repeated cleaning are important, buyers should also confirm whether a hard-coated or abrasion-resistant PC surface is required rather than assuming standard sheet offers the same surface durability.
Applications of Polycarbonate Sheet
| Application | Typical Use |
| Sound Insulation | Partition walls, transparent sound barriers and selected freeway-barrier systems |
| Construction | Glazing, transparent panels and selected building applications |
| Electronic Appliances | Selected insulating and fabricated components subject to grade requirements |
| Mechanical Equipment | Equipment housings, guards and fabricated parts where suitable |
| Medical Equipment | Selected components only when the required material grade and regulatory documentation are confirmed |
Partition Wall Application
![Polycarbonate Sheet for Construction]()
Construction Application
![8mm PC Sheet for Freeway Barriers]()
Freeway Barrier Application
Discuss Your Sound Barrier Project
What Buyers Should Confirm Before Ordering
| Project Requirement | Information to Provide |
| Application | Partition wall, highway barrier, construction glazing or other use |
| Thickness | 6mm, 8mm, 10mm or required customized thickness |
| Panel Size | Required width × length and dimensional tolerance |
| Color | Transparent, milk white, opaque white or required color |
| Surface | Smooth, frosted, glossy or matte |
| Acoustic Requirement | Required dB reduction and acoustic test standard |
| Outdoor Exposure | UV requirement, climate and expected service environment |
| Structural Requirement | Wind load, frame spacing, deflection and fixing system |
| Impact Requirement | Required impact test or project safety specification |
| Fire Requirement | Required fire-test standard and classification |
| Quantity | Project quantity and repeat demand |
| Destination | Country, port and required delivery schedule |
Get a Polycarbonate Sheet Quote
Product Documents and Project Approval
The existing HSQY product information lists ISO 9001:2008, SGS and ROHS documentation.
ISO 9001 is a quality-management system standard and should not be interpreted as independent certification of acoustic performance, fire rating, impact resistance or medical suitability for every individual polycarbonate sheet.
For infrastructure, partition or engineering projects, provide the required test standards and document list before ordering so the applicable sheet grade and supporting reports can be confirmed.
Packing and Delivery
Standard Packaging: Protective wrapping and export pallets are listed for bulk transportation.
Custom Packaging: Existing product information states that logo or customized packaging designs can be discussed.
Large Orders: International shipping arrangements can be selected according to panel dimensions, project quantity and destination.
Sample Shipping: Existing product information lists TNT, FedEx, UPS and DHL for small shipments and samples.
![Packing for Sound Insulation Polycarbonate Sheet]()
Polycarbonate Sheet Packing
Frequently Asked Questions About Sound Insulation Polycarbonate Sheet
What is a sound insulation polycarbonate sheet?
It is a solid polycarbonate panel used as part of partition walls, transparent acoustic barriers and related construction systems where visibility, impact resistance and sound separation are required.
Are 6mm, 8mm and 10mm polycarbonate sheets suitable for sound barriers?
These thicknesses are listed for the current product and can be used in suitable sound-barrier or partition systems. Final thickness selection should consider acoustic requirements, panel dimensions, supporting structure, wind load and project standards.
How much sound can a polycarbonate sheet block?
This product page does not provide a verified dB value for the individual 6mm, 8mm or 10mm sheet. Actual acoustic performance depends on the test method and complete barrier or partition system, including the frame, joints, seals and installation geometry.
Does a thicker polycarbonate sheet provide better sound insulation?
Increasing solid panel thickness generally increases panel mass and rigidity, but total sound reduction cannot be determined from thickness alone. The complete barrier or partition design must also be considered.
What colors are available?
The current product description lists transparent, opaque white and milk white. The product attribute section also lists clear, clear with color and opaque-color options.
What surface finishes are available?
Smooth, frosted, glossy and matte surfaces are listed in the current product specification.
How much light can clear polycarbonate transmit?
The current HSQY description lists light transmission up to approximately 88%. Actual transmission depends on thickness, color, surface finish and PC grade.
Is polycarbonate stronger than glass?
Polycarbonate is commonly selected for projects requiring substantially higher impact resistance than conventional glass. The existing HSQY description states up to 80 times the impact resistance of glass under its referenced conditions. Request the applicable test data when a specific impact value is required.
Is polycarbonate completely unbreakable?
No material should be treated as absolutely unbreakable. Polycarbonate offers high impact resistance, but failure can occur under sufficiently severe impact, structural loading, installation stress or environmental conditions.
Can these polycarbonate sheets be used outdoors?
Outdoor applications should use a suitable UV-protected PC grade. Confirm the required UV configuration, climate, exposure duration and project specification before ordering sheets for highway or exterior construction applications.
What is the fire rating?
The current product description lists Class B1 fire resistance. Buyers requiring a defined fire classification should request the applicable test standard and report for the exact material grade and thickness.
Can the sheets be printed?
The existing product specification lists CMYK offset printing, silk-screen printing, UV security printing and laser printing. Printing compatibility should be tested on the selected PC grade and surface before mass production.
Can the sheet size be customized?
Yes. The current product attributes list 1220 × 2400mm and 1200 × 2150mm standard references together with custom-size availability.
Can I request a sample before a bulk order?
The existing product information states that samples are available with courier freight covered by the buyer. Confirm the required thickness, color, surface and size before arranging shipment.
What information should I provide for a quotation?
Provide the required thickness, panel dimensions, color, surface, quantity, application, acoustic requirement, UV exposure, wind load, frame spacing, project standards, destination and required documentation.
Request Sound Insulation PC Sheet Pricing
About HSQY Plastic Group
HSQY Plastic Group supplies polycarbonate sheets and other plastic sheet materials to international B2B customers for construction, partition, glazing, fabrication and industrial applications.
HSQY works with contractors, panel-system manufacturers, noise-barrier fabricators, distributors and engineering companies requiring standard or customized polycarbonate sheet specifications.
For 6mm, 8mm or 10mm sound-insulation polycarbonate sheet projects, provide your required panel dimensions, application, acoustic specification, surface, color, quantity and destination so the appropriate specification can be confirmed.
