gypsum ceiling film
HSQY Plastic
HSQY-210630
0.075mm
white / different color
1220mm*500m
2000 KG.
| Availability: | |
|---|---|
Product Description
HSQY Plastic Group supplies decorative PVC film for gypsum ceiling tile lamination and interior ceiling panel manufacturing. The film is used as a decorative facing layer on compatible gypsum boards, providing patterned, embossed or colored surfaces for finished suspended ceiling tiles.
The featured decorative PVC film is listed at 0.075mm thickness and 1220mm width. More than 100 decorative designs are referenced across the product range, allowing ceiling manufacturers and building material distributors to select different surface appearances for their target markets.
This product is primarily intended for gypsum ceiling board lamination. It is supplied as a thin PVC roll film and should not be confused with a standalone stretch ceiling membrane installed directly with perimeter profiles.
HSQY works with gypsum ceiling tile manufacturers, decorative panel converters, building material wholesalers, importers and distributors requiring PVC facing films in bulk quantities.
Decorative PVC Ceiling Facing Film
Decorative PVC Film Surface
Decorative PVC ceiling film is a thin polyvinyl chloride facing material used in the production of laminated gypsum ceiling tiles. It creates the visible color, pattern and surface texture of the finished ceiling panel.
During production, the PVC film is laminated onto a prepared gypsum board using an adhesive system and manufacturing process appropriate to the substrate and film grade. The laminated board can then be cut and processed into finished ceiling tiles.
Decorative designs may include white surfaces, geometric patterns, embossed textures and other color combinations. The required design, gloss, texture and color consistency should be confirmed according to the finished ceiling product.
The following table summarizes the published product information supplied for this decorative PVC ceiling film.
| Property | Specification |
|---|---|
| Product Name | Decorative PVC Film for Gypsum Ceiling Tiles |
| Alternative Names | PVC Ceiling Lamination Film, PVC Facing Film, Embossed PVC Ceiling Film |
| Material | Polyvinyl Chloride (PVC) |
| Nominal Thickness | 0.075mm |
| Standard Width | 1220mm |
| Reference Density | 1.36g/cm³ |
| Design Options | More Than 100 Listed Designs |
| Color Options | White, Decorative Colors and Custom Designs |
| Surface Options | Decorative and Embossed Surface According to Selected Design |
| Supply Format | PVC Roll Film |
| Main Application | Surface Lamination for Gypsum Ceiling Boards and Ceiling Tiles |
| Customization | Thickness, Width, Color and Decorative Pattern According to Confirmed Requirements |
| Listed MOQ | 1000kg |
| Payment Terms | 30% Deposit and 70% Balance Before Shipment, Subject to Commercial Agreement |
| Delivery Terms | FOB, CIF, EXW |
| Production and Delivery Schedule | Confirmed According to Pattern, Quantity and Production Arrangement |
Decorative Surface: Provides a finished pattern, color or embossed texture for compatible ceiling boards.
Multiple Design Options: More than 100 designs are referenced for different ceiling collections and interior styles.
Thin PVC Facing: The featured 0.075mm material is designed as a decorative surface layer rather than a rigid structural board.
1220mm Standard Width: Suitable for common gypsum ceiling board lamination processes.
Roll Supply: Supports continuous production on suitable lamination equipment.
Custom Design Requirements: Colors, patterns and surface finishes can be discussed according to purchase requirements.
Interior Ceiling Applications: Intended for decorative ceiling tile products used in commercial and residential interiors.
Decorative PVC film can be laminated onto compatible gypsum boards to create finished ceiling tiles with decorative surfaces. The film provides the visible color, pattern and texture of the final panel.
PVC-faced gypsum tiles can be manufactured for compatible suspended ceiling systems. The decorative film covers the board surface, while the finished rigid tile is supported by the ceiling grid.
Decorative ceiling panels may be used in offices, retail stores, showrooms and other commercial interiors where consistent ceiling colors and patterns are required.
Different decorative designs can be selected for ceiling panels used in suitable hotel, restaurant, reception and hospitality environments.
Building material suppliers and ceiling tile producers can develop different decorative ceiling collections using selected PVC film patterns and finishes.
PVC Film for Gypsum Ceiling Tiles
Decorative PVC Ceiling Panel Application
Decorative PVC facing film and PVC stretch ceiling membrane are different product types. Buyers should distinguish them according to the manufacturing and installation method.
| Comparison | Decorative PVC Facing Film | PVC Stretch Ceiling Membrane |
|---|---|---|
| Primary Function | Decorative facing layer on a rigid board | Independent flexible ceiling surface |
| Substrate | Compatible gypsum or other rigid board | No rigid board facing required |
| Manufacturing | Laminated onto the board surface | Prepared as a flexible membrane |
| Installation | Finished rigid tile installed in a compatible ceiling grid | Membrane tensioned into dedicated perimeter profiles |
| Main Selection Factors | Thickness, width, pattern, surface, adhesion and board compatibility | Membrane width, tension, welding and installation-system compatibility |
The appearance of the finished ceiling tile depends on the selected film design. Buyers can evaluate decorative films according to color, pattern, embossing and surface finish.
| Design Type | Selection Considerations |
|---|---|
| White Decorative Film | Clean and neutral appearance for standard ceiling collections |
| Embossed Patterns | Surface texture for a more decorative finished ceiling tile |
| Geometric Designs | Modern visual patterns for commercial ceiling applications |
| Colored Decorative Film | Color coordination with specific interior design programs |
| Custom Patterns | Provide design reference, color requirements and purchase quantity for evaluation |
Explore our Embossed PVC Film collection for related decorative ceiling film options.
Specify the required color, pattern, embossing and surface appearance. A reference image, design code or approved sample can help define the intended finished appearance.
The listed standard thickness is 0.075mm. Other thickness requirements should be confirmed according to the selected design and lamination process.
The listed standard width is 1220mm. The required width should allow for the gypsum board dimensions and any trimming needed during production.
Provide information about the gypsum board or other intended rigid substrate, including surface condition, board dimensions and production process.
The film should be evaluated with the intended adhesive and lamination equipment. Temperature, pressure, line speed and surface preparation can affect the finished result.
Buyers may specify acceptable color variation, pattern alignment, embossing consistency, wrinkles, surface marks and other appearance requirements.
Provide the required film specification, design, quantity, packaging needs, delivery destination and commercial requirements for quotation.
Decorative PVC film should be packed to protect the film surface, decorative pattern, roll edges and winding condition during handling and export transportation.
Small Roll Packaging: The original product information references small rolls packed in PE bags and cartons.
Film Roll Packaging: PVC film rolls can be protected with PE film and packed in cartons or suitable pallet configurations.
Pallet Packaging: The original product information references approximately 500–2000kg per plywood pallet. Actual pallet weight depends on roll size and shipment configuration.
Container Loading: Actual container quantity depends on roll dimensions, weight, carton size, pallet configuration and applicable transport limits.
Delivery Terms: FOB, CIF and EXW options are listed and should be confirmed in the commercial agreement.
For decorative PVC ceiling film, important purchasing criteria may include thickness consistency, width, roll condition, color consistency, pattern alignment, embossing definition, surface appearance and lamination compatibility.
The original product information references SGS and ISO 9001:2008 documentation. Buyers requiring specific material, chemical, fire-performance or project documentation should confirm that the applicable document covers the selected PVC film grade and intended use.
HSQY Plastic Group participates in international trade exhibitions and communicates with ceiling tile manufacturers, building material distributors, plastic film converters and international buyers.
2024 Mexico Exhibition
2025 Philippines Exhibition
2024 American Exhibition
2017 Shanghai Exhibition
2018 Shanghai Exhibition
2023 American Exhibition
Decorative PVC ceiling film is a thin PVC facing material used to create the visible patterned, colored or embossed surface of compatible gypsum ceiling tiles.
Its primary application is surface lamination for gypsum ceiling boards and ceiling tiles used in interior suspended ceiling systems.
The listed thickness for this product is 0.075mm. Other thickness requirements should be confirmed according to the selected design and manufacturing process.
The listed standard width is 1220mm. Custom width requirements can be discussed according to the lamination equipment and board dimensions.
The product information references more than 100 decorative designs. Specific patterns and colors should be confirmed for the selected order.
Custom color and pattern requirements can be discussed. Buyers should provide a design reference, required dimensions and order quantity.
No. This product is mainly intended as a decorative facing film laminated onto a rigid ceiling board. A stretch ceiling membrane is installed independently using a tensioning system.
Yes. Gypsum ceiling board lamination is the primary stated application for this decorative PVC film.
No. The film is first laminated onto a rigid board. The completed ceiling tile can then be installed in a suitable suspended ceiling grid system.
Manufacturers should evaluate the selected film with the intended board substrate, adhesive, lamination temperature, pressure, line speed and finished surface requirements.
Yes. Embossed surface designs are among the decorative options referenced for ceiling-facing PVC films.
The film is intended for decorative ceiling panels that may be used in appropriate offices, retail spaces, hotels and other interior applications, subject to the performance requirements of the completed ceiling system.
Fire performance depends on the selected PVC formulation, applicable testing method and completed ceiling assembly. Required fire-performance documentation should be confirmed for each project.
The detailed product information lists a minimum order quantity of 1000kg. The applicable quantity for customized designs should be confirmed before ordering.
Please provide the required film thickness, width, pattern, color, surface finish, substrate type, lamination process, purchase quantity, packaging requirements and delivery destination.
Changzhou Huisu Qinye Plastic Group Co., Ltd. is located in Changzhou, Jiangsu, China. HSQY supplies PVC films, PVC sheets, PET materials and other plastic products for packaging, decorative panel manufacturing and industrial converting applications.
HSQY works with gypsum ceiling tile manufacturers, decorative board processors, building material distributors, film converters and international importers. Buyers can discuss decorative pattern selection, film specifications and bulk purchasing requirements.
Company Information
Choose us, choose reliable quality and service:
(1) Profession and experience making us stably doing greatly in design service and qualify production for you.
(2) Efficiency team to ensure quick settling all your questions and concerns.
(3) Win-win conception as our action guide that we've always been doing well with our current partners to offer the best price-performance for you.
Packing details of ceiling embossed PVC film: packing with round cartons or square cartons and sponge films as your choice.
20' FCL: 100-160 rolls, 70000-80000 meters, 7000-8000 kg
40' FCL: 200-285 rolls, 160000-210000 meters, 14600-21000 kg
