China Supplier Pvc Sheet for Folding Box Printable

HSQY supplies printable rigid PVC sheets for folding boxes in 0.06–6.5 mm thickness, with clear, semi-transparent and opaque options for printing, die cutting and packaging.
  • 1000 KG.

Availability:

Product Description

Printable PVC Sheet for Folding Boxes

HSQY Printable PVC Sheet for Folding Boxes is a rigid polyvinyl chloride material developed for transparent packaging, printed folding cartons and retail display applications. Its smooth surface, high transparency and suitable processing characteristics make it a practical material option for packaging manufacturers, printing companies and plastic sheet distributors.

The PVC sheets are available in calendered and extruded grades, covering thicknesses from 0.06 mm to 6.5 mm. Standard sheet dimensions include 700 × 1000 mm, 900 × 1200 mm and 915 × 1220 mm, with customized sizes available according to production requirements.

Suitable PVC grades can be evaluated for UV offset printing, screen printing, die cutting, creasing and folding. They are commonly considered for cosmetic packaging, gift boxes, electronics packaging, stationery cartons and other transparent retail packaging.

Request Printable PVC Sheet Quote

Printable PVC Sheet Specifications

HSQY offers two production processes for rigid PVC sheets: extrusion and calendering. Buyers can select the appropriate production grade according to thickness, sheet dimensions, printing requirements and final packaging applications.

Specification Extrusion Calendering
Material Rigid PVC Rigid PVC
Thickness 0.21–6.5 mm 0.06–1.0 mm
Roll Width 200–1300 mm 200–1500 mm
Standard Sheet Sizes 700 × 1000 mm, 900 × 1200 mm, 915 × 1220 mm 700 × 1000 mm, 900 × 1200 mm, 915 × 1220 mm
Customized Sizes Available Available
Density 1.36 g/cm³ 1.36 g/cm³
Color Transparent, semi-transparent, opaque Transparent, semi-transparent, opaque
Samples A4 size and customized A4 size and customized
MOQ 1,000 kg 1,000 kg
Loading Port Ningbo, Shanghai Ningbo, Shanghai

Note: The specifications represent the available production ranges. Final thickness, dimensions, surface requirements and printing compatibility should be confirmed according to the selected PVC grade and approved samples.

Printing Compatibility of PVC Folding Box Sheets

Printable rigid PVC sheets are used by packaging converters to produce transparent cartons with customized graphics, logos, product information and decorative patterns. The printing process should be selected according to the PVC surface, ink formulation, artwork and required printing quality.

UV Offset Printing

UV offset printing can be evaluated for suitable rigid PVC sheets when packaging manufacturers require detailed graphics, logos, product information and multi-color designs. Ink compatibility, curing conditions and adhesion should be tested on the selected PVC grade before mass production.

Screen Printing

Screen printing is another printing method that can be considered for suitable PVC packaging sheets. It is commonly used for logos, text, decorative graphics and selected opaque printing areas. The ink system and surface compatibility should be confirmed through actual printing tests.

Transparent and Opaque Printing Areas

Transparent PVC packaging can combine unprinted clear areas with printed sections. This allows consumers to view the packaged product while displaying brand information, instructions and promotional graphics.

White Ink Printing on Clear PVC

White ink can be used as an underbase beneath selected printed colors on transparent PVC sheets. It helps create more opaque graphics and improve color visibility when the packaged product is visible through the material. Buyers should specify the required white ink coverage and transparent areas in the artwork.

Ink Adhesion and Surface Compatibility

Ink adhesion is an important consideration when printing on rigid PVC. The selected sheet surface, ink formulation, printing equipment and curing conditions all influence the final printing result. If a specific surface treatment or surface-energy requirement is needed, it should be confirmed before ordering. A print test using the actual material is recommended.

Key Features of Printable PVC Sheet

  • High Transparency: Clear PVC provides good product visibility for transparent folding cartons and retail display packaging.

  • Smooth Surface: A smooth and uniform surface without noticeable flow lines or crystal points supports an attractive packaging appearance.

  • Printing Applications: Suitable grades can be evaluated for UV offset printing and screen printing using compatible ink systems.

  • Folding Performance: The material is designed for folding box applications, with attention to reducing visible crease whitening under suitable processing conditions.

  • Multiple Thickness Options: Calendered and extruded production grades cover different thickness and rigidity requirements.

  • Customized Dimensions: Available in standard sheet sizes, customized sheets and rolls.

  • Color Options: Transparent, semi-transparent and opaque PVC sheets are available.

PVC Sheet Production Processes

Extrusion

PVC extrusion is a continuous production process that enables efficient manufacturing of rigid PVC sheets. It supports a broad thickness range from 0.21 mm to 6.5 mm and is suitable for different plastic sheet applications.

Calendering

Calendering is widely used to manufacture polymer films and thin sheets. The process produces a smooth PVC surface and is suitable for thin packaging sheet applications. HSQY calendered PVC sheets are available in thicknesses from 0.06 mm to 1.0 mm.

PVC Folding Box Sheet Product Images

Printable PVC folding box sheet product sample 1

PVC Folding Box Sheet – Sample 1

Printable PVC folding box sheet product sample 2

PVC Folding Box Sheet – Sample 2

Applications of Printable PVC Sheets

Printable PVC sheets are widely used in packaging applications where product visibility and printed brand communication are both important. They can be converted into different folding carton structures according to packaging design and production requirements.

  • Cosmetic Packaging: Transparent boxes for skincare products, perfume, makeup accessories and beauty gift sets.

  • Gift Packaging: Printed transparent cartons for promotional gifts, premium products and decorative packaging.

  • Electronics Packaging: Clear packaging for cables, chargers, electronic accessories and small components.

  • Stationery Packaging: Printed and transparent boxes for pens, office supplies and stationery products.

  • Toy Packaging: Transparent folding cartons for toys, models and collectible products.

  • Retail Packaging: Customized transparent packaging for consumer goods and promotional products.

  • Paperboard Window Packaging: Clear PVC panels used with paperboard cartons to display packaged products.

Transparent PVC folding box packaging application sample 1

PVC Folding Box – Application Sample 1

Transparent PVC folding box packaging application sample 2

PVC Folding Box – Application Sample 2

Die Cutting, Creasing and Folding

After printing, PVC sheets can be converted into folding box blanks through suitable cutting and creasing processes. The finished packaging structure depends on the box design, material thickness, folding direction and converting equipment.

Die Cutting

Die cutting shapes the PVC sheet according to the packaging dieline. Cutouts, tabs, openings and carton outlines can be incorporated into the flat sheet design.

Creasing and Folding

Creasing creates controlled fold lines so the PVC sheet can be assembled into the intended box structure. Crease depth, tooling pressure, material thickness and folding direction should be matched to minimize cracking, whitening and unwanted deformation.

Bonding and Box Assembly

Depending on the packaging design, converted PVC sheets can be assembled using suitable adhesive seams, tuck tabs or locking structures. Buyers should confirm the required box construction and bonding method when selecting the material.

PVC Sheet Packaging and Delivery

HSQY PVC sheets are packed to protect the material during storage and international transportation.

  • Standard Packaging: Kraft paper wrapping and export pallets.

  • Paper Tube Core: 76 mm diameter.

  • Customized Packaging: Customized packaging and logo printing can be discussed according to order requirements.

  • Loading Ports: Ningbo Port and Shanghai Port.

PVC sheet export packaging with kraft paper wrapping and export pallet

Samples and Bulk Orders

A4-size and customized PVC sheet samples are available for material evaluation. Printing companies and packaging converters can assess surface appearance, transparency, ink adhesion and folding performance using their intended printing and converting processes.

The standard minimum order quantity is 1,000 kg. Customized thicknesses, roll widths, sheet dimensions and colors can be discussed according to project requirements.

For an accurate quotation, please provide the required PVC grade, thickness, sheet size, printing method, artwork requirements, estimated quantity and final packaging application.

Frequently Asked Questions About Printable PVC Sheets

1. Can rigid PVC sheets be used for printing?

Yes. Suitable rigid PVC sheet grades can be evaluated for printing applications. Printing compatibility depends on the sheet surface, ink formulation, printing equipment and curing conditions. Testing is recommended before mass production.

2. Which printing methods can be used on PVC folding box sheets?

UV offset printing and screen printing can be evaluated for suitable PVC grades. The final printing method should be selected according to artwork, order quantity, ink compatibility and required printing quality.

3. Does PVC sheet need surface treatment before printing?

Surface treatment requirements depend on the PVC grade, surface condition, ink system and printing equipment. If your printing process requires a specific surface-energy level or corona treatment, please provide the technical requirements before ordering.

4. Why is white ink used when printing on transparent PVC?

White ink is commonly used as an underbase to make selected printed areas more opaque. It helps improve the visibility of colors and text on transparent PVC while allowing other areas to remain clear for product display.

5. Can printed PVC sheets be die-cut and folded?

Yes. Suitable PVC sheets can be processed through die cutting, creasing and folding. Material thickness, crease depth, tooling conditions and folding direction should be evaluated together to achieve consistent packaging quality.

6. What thicknesses are available for printable PVC sheets?

Calendered PVC sheets are available from 0.06 mm to 1.0 mm, while extruded PVC sheets are available from 0.21 mm to 6.5 mm. The appropriate thickness depends on packaging dimensions, required rigidity and printing and folding processes.

7. What sheet sizes are available?

Standard sheet sizes include 700 × 1000 mm, 900 × 1200 mm and 915 × 1220 mm. Customized sheet dimensions and roll widths are also available.

8. What colors are available?

HSQY PVC sheets are available in transparent, semi-transparent and opaque options. Customized color requirements can be discussed according to the packaging project.

9. Can I request a sample before placing a bulk order?

Yes. A4-size and customized samples are available. Printing companies can use samples to evaluate transparency, printing compatibility, ink adhesion and folding performance before confirming bulk production.

10. What is the minimum order quantity for PVC folding box sheets?

The standard MOQ is 1,000 kg. Please contact HSQY to confirm the order requirements for customized thicknesses, dimensions and colors.

11. Is printable PVC sheet suitable for direct food contact?

Food-contact suitability depends on the specific PVC formulation, additives, printing inks, contact conditions and destination-market regulations. General-purpose printable PVC sheets should not automatically be considered suitable for direct food contact. Please specify your application and required compliance documentation before ordering.

Request a Printable PVC Sheet Quotation

Looking for a reliable printable PVC sheet manufacturer for your folding box production? HSQY supplies rigid PVC sheets in calendered and extruded grades for packaging manufacturers, printing companies, distributors and wholesale buyers.

Send us your required thickness, sheet dimensions, printing method, color, artwork requirements and estimated order quantity. Our team can help review your material specifications and provide suitable product options and a quotation.

Contact HSQY for Pricing and Samples
